| Processor | Two 2nd or 3rd Generation AMD EPYCTM Processors with up to 64 cores per processor |
| Memory | Up to 32 x DDR4 Maximum RAM RDIMM 2 TB LRDIMM 4TB Max Bandwidth up to 3200 MT/S |
| Availability | Hot plug redundant Hard drives, Fans, PSUs |
| Controllers | PERC 10.5 – HBA345, H345, H745, H840, 12G SAS HBA PERC 11 – H755, H755N Chipset SATA/SW RAID (S150): Yes |
| Drive Bays | Front Bays Up to 4 x 3.5” hot plug SAS/SATA (HDD) Up to 8 x 2.5” hot plug SAS/SATA (HDD) Up to 12 x 2.5” (10 Front + 2 Rear) hot plug SAS/SATA/NVMe Optional Internal: 2 x M.2 (BOSS) Optional Rear: 2 x M.2 (BOSS-S2) |
| Power Supplies | 800W Platinum 1400W Platinum 1100W Titanium |
| Fans | Hot plug Fans |
| Dimensions | Height: 42.8mm (1.7”) Width: 434.0mm (17.1”) Depth: 736.54mm (29”) Weight: 21.8kg (48.06lbs) |
| Embedded mgmt | iDRAC9 iDRAC RESTful API with Redfish iDRAC Direct Quick Sync 2 BLE/wireless module |
| Bezel | Optional LCD bezel or security bezel |
